About Flush Board
RIMDOOR, the premium grade flush door with the advantage of more layers is a durable product for its excellent quality, exceptional finish, and unique demonstrational stability. It is made of selected hardwood frames and accurate battens. It is evenly constructed with the same species of timber that matters the most in providing longer life. Stiles, rails, and wooden strips are kiln-seasoned and are treated with eco-friendly preservatives.
BWP-grade of phenol formaldehyde resin is used to bond the layers. The phenolic resin conforms to IS 848: 1974. The specification is mixed with unique additives to enhance the protection characteristics. RIMDOORS have an extra lock rail that provides sufficient strength to handle and knobs. Its hardwood forms provide high strength for fitting hinges and deviation resistance.
Test | Requirement of IS 2202 | Test Result |
|---|---|---|
Dimensions & Squareness | Length, width: +/-5mm Thickness: +/-1mm Squareness:1mm at a length of 500mm | Length, width: +/-5mm Thickness: +1mm/-0.2mm Squareness: < 1mm at a at a length of 500mm |
General Flatness | <6.0m | <4.0mm |
Impact Indentation | <0.2mm Max. Deflection -<5.0 mm | <0.2mm Max Deflection -<3.0mm |
Edge Loading Test | Residual deflection -<0.5mm Lateral buckling -<2.0mm | Residual deflection -<0.5mm Lateral buckling -<1.0mm |
Shock Resistance Test | Should withstand 5 blows | Can withstand 25 blows |
Misuse Test | Pass | Excellent |
End Immersion Test | Should have no de-lamination at the end of the test | There is no de-lamination at the end of the test |
Knife/Glue Adhesion – Test Screw Withdrawal Resistance | Pass > 1000 N | Excellent > 1500 N |
